Pristatymas - 14 dienųSpecifications: |
|---|
| Electrical |
|---|
|
Standard |
SMR, AMPS, CDMA, TDMA, GSM 900 |
PCS, DECT, GSM 1900, UMTS |
Bluetooth, ISM, WLAN |
|
Frequency range |
806 - 960 MHz |
1.71 - 2.17 GHz |
2.4 - 2.5 GHz |
|
Gain,typ. |
8.5 dBi |
7.5 - 10 dBi |
5 - 6.5 dBi |
|
VSWR, max. |
2:1 |
1.7:1 |
1.7:1 |
|
3 dB Beam-Width, H-Plane, typ. |
75 ° |
60 ° |
50 ° |
|
3 dB Beam-Width, E-Plane, typ. |
65 ° |
45 ° |
25 ° |
| Polarization |
Linear Vertical |
| Input power, max |
50 Watt |
| Input Impedance |
50 Ohm |
| Lightning Protection |
DC Grounded |
| Mechanical |
|---|
| Dimensions (HxWxD) | 230 x 214 x 31 mm (9.1"×8.4"×1.2") |
| Weight | 0.5 kg |
| Connector | N-Type,Female |
| Back Plane | Aluminum; protected through chemical passivation |
| Radome | UV Protected Polycarbonate |
| Mount | See Ordering Options |
| Environmemtal |
|---|
| Operating Temperature Range | - 40°C to + 65°C |
| Vibration | According to IEC 60721-3-4 |
| Wind Load | 200 km/h (survival) |
| Flammability | UL94 |
| Water Proofing | IP-65 |
| Humidity | ETS 300 019-1-4, EN 302 085 (annex A.1.1) |
| Ice and Snow | 25mm radial (survival) |
| Salt Fog | According to IEC 68-2-11 |
| Service Life | >10 years |
Specification PDFTurite klausimų? Susisiekite...
|
|
